Crabtree CSPD7462/1 Loadstar Type 2 SPD for 1P 3-wire Systems (2 Modular Width)

Crabtree CSPD7462/1 Loadstar Type 2 SPD for 1P 3-wire Systems (2 Modular Width)

Crabtree CSPD7462/1 Loadstar Type 2 SPD for 1P 3-wire Systems (2 Modular Width)

by Crabtree
SKU CSPD7462/1
£107.49

Description

Crabtree CSPD7462-1 Loadstar Type 2 SPD for 1P 3-wire Systems (2 Modular Width)

From consumer units and fuse boards, circuit protection devices, to cable management. Crabtree has the right products for a wide variety of domestic to commercial circuit protection installations. Crabtree circuit protection ranges are made to the highest standards, as safety is paramount. They are resettable devices that protect circuits against overload or overcurrent. They ensure efficient operation and protection of all their consumer unit with devices, including MCBs, RCBOs, RCDs, isolator switches, and surge protection devices to suit all areas of installation where protection is needed.

Surge protection kits (type 2) are suitable for integral installation within 125A and 250A distribution boards. Also stand stand-alone surge protection units are suitable for mounting in DIN-rail enclosures in type 1, type 2, and type 1 & 2. These devices will provide an installation with protection against transient overvoltages of atmospheric origin or due to switching.

Key Features

  • Accessory for all Crabtree sub-distribution boards (except Fusestar)
  • SPD only, comes with plug-in modules
  • 2 modules wide

Specifications

Surge Protection|Description|Product Surge Protection Device
Surge Protection|Description|Type Module
Surge Protection|Features|Ingress Protection IP20
Surge Protection|Features|Status Indicator Y
Surge Protection|Features|Number of Poles 2P
Surge Protection|Features|Mounting Type DIN Rail
Surge Protection|Features|Plug-In Module Y
Surge Protection|Features|Surge Protector Type Type 2
Surge Protection|Features|Voltage Type AC
Surge Protection|Features|Number of Modules 2
Surge Protection|Dimensions|Maximum Cable Size 25|35 mm2
Surge Protection|Technical Data|Nominal Voltage 350 V
Surge Protection|Technical Data|Rated Short Circuit Withstand Current 25 kA
Surge Protection|Technical Data|Nominal Discharge Current 20 kA
Surge Protection|Technical Data|Maximum Discharge Current 40 kA
Surge Protection|General|CE Approved Y
Surge Protection|General|UKCA Approved Y
Manufacturer Crabtree Electrical Industries Ltd
