Remarks:
IP66: using the membrane entry
Ø cable: 5,2 - 17 mm
IP67: using the threaded entry together with ESKV cable gland
Ø cable: 9,0 - 17 mm
Mounting:
- 4 internal openings outside of the sealing area
Equipment:
- 7 elastic, self-sealing puncture-membranes for cable entry on the side and 3 on the bottom
- 7 integrated M25 thread for mounting without lock nut
- 4 captive cover screws
- terminal block 5-pole, 6mm²
- 2 reduction adaptors KRM 25/20
| Material |
Polypropylene |
| Material sealing gasket |
TPE |
| Temp. range min |
-30 °C |
| Temp. range max |
100 °C |
| Temperatures during install. |
-5 °C - 60 °C |
| Protection class |
IP66 / IP67 |
| Glow wire test |
750 °C |
| Voltage |
690 V |
| Rated current / A (Terminal) |
41 A |
| Rated cross section |
5 x 6mm² |
| Terminals/poles |
6 mm² |
| Fixing |
4 internal openings |
| Ø cable diameter min |
5,2 mm |
| Ø cable diameter max |
17 mm |
| External dimensions LxWxH |
110 x 110 x 66 mm |
| Using for cable gland |
 |
| Product Color |
RAL 9005 |
| WISKA-Order no. |
10061779 |
| Type |
COMBI 607/5/2xKRM25/20 BK |
| Packing unit |
3 |
| ETIM-Classification |
EC002600 |
