Crabtree 380/A030 Starbreaker 800A Double Pole 30mA Type A RCD

Crabtree 380/A030 Starbreaker 800A Double Pole 30mA Type A RCD

Crabtree 380/A030 Starbreaker 800A Double Pole 30mA Type A RCD

by Crabtree
SKU 380/A030
£44.85

Description

The name behind one of the widest ranges of wiring accessories, circuit protection and control equipment, covering residential, commercial and industrial markets worldwide. Known for innovative new products and concepts, Crabtree's uncompromising approach to quality has long established this brand as a market leader, with everyone who takes pride in a job done professionally.

The Crabtree 380/A030 is a double pole, Type A, 80A main incoming RCCB from the Starbreaker range. This electro-mechanical device has a 30mA sensitivity and a 50mm² terminal capacity.

  • Double pole RCD
  • Plug-in to Starbreaker boards
  • 80A 30mA
  • Type-A current leakage type
  • Rated impulse withstand voltage: 4kV
  • Terminal capacity: 50mm Squared
  • BS EN 61008

Specification

Dimension 80A 30mA
Circuit Breakers|Description|Product RCCB
Circuit Breakers|Features|Pole Configuration Double Pole (2P)
Circuit Breakers|Features|Number of Modules 2
Circuit Breakers|Features|Mounting DIN Rail
Circuit Breakers|Features|Ingress Protection IP20
Circuit Breakers|Features|Sensitivity 30.00 mA
Circuit Breakers|Dimensions|Cable Capacity 50 mm2
Circuit Breakers|Technical Data|RCD Type/Class A
Circuit Breakers|Technical Data|Current Rating 80 A
Circuit Breakers|Technical Data|Voltage 230 V
Circuit Breakers|Technical Data|Frequency 50 Hz
Circuit Breakers|General|CE Approved Y
Circuit Breakers|General|UKCA Approved Y
Manufacturer Crabtree Electrical Industries Ltd
Brand Starbreaker
